XH-W3001 12V Digital Thermostat Controller | 120W Temperature Control Switch with LED Display

Technical Specifications

• Model: XH-W3001
• Operating Voltage: DC 12V
• Power Rating: Max 120W
• Temperature Measurement Range: -50°C to +110°C
• Control Accuracy: ±0.1°C
• Display Type: LED Digital Display (Red)
• Output Type: Relay Output
• Relay Capacity: 10A (Max Load 120W at 12V)
• Sensor Type: Waterproof NTC 10K Temperature Probe
• Temperature Setting Range: -50°C to +110°C
• Working Mode:
  • Heating Mode (increase temperature)
  • Cooling Mode (reduce temperature)
• Wiring:
  • Input: 12V DC
  • Output: Normally Open/Closed relay terminals
• Features:
  • Over-temperature protection
  • High precision temperature control
  • User-defined temperature threshold
  • Easy 3-button interface
• Applications:
  • Incubators
  • Aquariums
  • Water heaters
  • Greenhouses
  • HVAC systems
  • DIY temperature control projects




Technical Description

The XH-W3001 DC 12V 120W Digital Thermostat Switch is a high-precision temperature controller designed for a wide range of heating and cooling applications. Equipped with a bright LED display and a waterproof NTC temperature sensor, this thermostat ensures accurate real-time monitoring and control from -50°C to +110°C.

The module features a relay-based switching output capable of handling up to 120W, making it ideal for incubators, aquariums, water heaters, greenhouse climate systems, and DIY automation projects. With simple 3-button programming, you can easily set upper and lower temperature limits, choose heating or cooling mode, and protect devices from over-temperature damage.

Reliable, compact, and easy to use, the XH-W3001 is a must-have thermostat module for electronics projects and temperature-controlled systems.
