GY-53 VL53L0X Laser ToF Distance Sensor Module | Time-of-Flight Ranging Sensor for Arduino, ESP32 & Robotics Projects

Technical Specifications

• Sensor Model: VL53L0X
• VL53L0X 3-in-1 ranging & gesture sensor
• 5V to 2.8V voltage regulator onboard
• Built-in signal level shifter
• Supports Serial & PWM output
• Accurate distance sensing independent of target surface
• Easy-to-use breakout board
• Supports basic gesture recognition
• Module Type: GY-53 Laser Distance Sensor
• Technology: Time-of-Flight (ToF) Laser Ranging
• Measurement Range: Approx. 30mm – 2000mm
• Operating Voltage: 2.6V – 5V DC
• Communication Interface: I2C
• Laser Type: Infrared Laser Emitter
• Resolution: High precision distance measurement
• Application: Distance sensing, obstacle avoidance, robotics, automation
• Compatible Boards: Arduino, ESP32, Raspberry Pi, STM32

Description

The GY-53 VL53L0X Laser ToF Distance Sensor Module is a high-precision ranging sensor that uses Time-of-Flight (ToF) technology to measure distances accurately. It is ideal for Arduino, ESP32, robotics, obstacle detection, and smart automation projects.
