DPDT Switch Button 16A Center Position 6 Pin | KCD4 Forward & Backward Rocker Switch

Technical Specifications

• Product Type: DPDT Rocker Switch
• Model: KCD4
• Configuration: DPDT (Double Pole Double Throw)
• Switch Positions: ON – OFF – ON (Center OFF)
• Current Rating: 16A
• Voltage Rating: 250V AC
• Terminals: 6 Pin / 6 Leg
• Actuation Type: Rocker Switch
• Mounting Type: Panel Mount
• Function: Forward & Backward Direction Control
• Body Material: Heat-Resistant Plastic
• Contact Material: Silver Alloy
• Size: 30x25x30 mm
• Application: Motor Direction Control, Power Switching
• Quantity: 1 Piece

Product Description

The KCD4 DPDT Rocker Switch 16A 250V is a heavy-duty forward and backward direction control switch with a center OFF position (ON-OFF-ON). Featuring 6 terminals (6-leg design), it allows easy polarity reversal, making it ideal for DC motor direction control, robotics, automation panels, and DIY electrical projects.

With a 16A high-current rating, this switch can safely handle demanding loads. Its sturdy rocker mechanism and panel-mount design ensure long-lasting, reliable performance in both home and industrial applications.
